400G QSFP56-DD Active Electrical Cable — Up to 7m, 8×56G PAM4
Price range: $936.00 through $1,012.00
- Compliant with QSFP-DD MSA and CMIS5.2
- Support 8x56G PAM4 electrical data rates
- Enables 400Gb/s transmission
- Link length up to 7m (30AWG)
- Typical power consumption <7.5W per end
- Single +3.3V power supply
- BER (Post-FEC) <10-15
- Operation case temperature: 0 to 70℃
- RoHS compliant
Note: Prices are exclusive of customs duties, import taxes, and VAT. Any additional charges imposed by your country are the buyer's responsibility.
Push your data center to 400 Gigabits per second over copper — no optics, no compromise. The AEC-400G-QDD delivers 8×56G PAM4 signals with sub-10⁻¹⁵ BER, reaching up to 7 meters while consuming less than 7.5W per end.
The Asteraix 400G QSFP56-DD Active Electrical Cable (AEC) is a hot-pluggable copper cable assembly designed for short-reach, high-density 400G interconnects inside data centers and HPC clusters. It transmits bidirectional 400Gbps data via 8 lanes of 56G PAM4 signaling — without a single optical component, making it more reliable and significantly more cost-effective than AOCs for distances up to 7 meters.
Built to the QSFP-DD MSA and CMIS 5.2 standards, the AEC-400G-QDD integrates a full I²C management interface for real-time monitoring and configuration. It supports post-FEC BER of <10⁻¹⁵ — an error rate so low, it’s effectively lossless — making it production-ready for latency-sensitive, mission-critical applications including AI/ML training clusters, financial trading networks, and hyperscale cloud interconnects.
Specifications
Module Form Factor | QSFP-DD type2 | Data Rate per Lane | 53.125Gbps (PAM4) |
Max. Data Rate | 400Gbps | Number of Data Lanes | 8 TX and 8 RX per module (PAM4) |
Media | Copper | Wire AWG | 30AWG |
Power Consumption | 7.5W Per End | Supply Voltage | 3.3V |
Op. Temperature | 0 to 70°C (32 to 158°F) | Protocols | QSFP-DD MSA and CMIS5.2 |
| Length | 1m, 2m, 3m, 5m |
|---|---|
| Compatible Brands | Generic, Asterfusion, Nvidia, Juniper, Cisco |
Warranty & Delivery Information
Warranty
Quality Certifications
Delivery Time
Our standard products are typically shipped within one week (business days).
For custom products, please contact customer service to inquire about the specific delivery time.
