200G QSFP56 Passive DAC

SKU:

DAC | QSFP56 to QSFP56 | 3m

  • Maximum aggregate data rate of 200Gb/s (4 × 50Gb/s)

  • Support data rates : 56Gb/s (Support 28GBaud PAM4)

  • I²C-based two-wire serial interface with customizable EEPROM signature

  • Low crosstalk design for dense port breakout applications

  • Meets IEEE 802.3bj, IEEE 802.3cd, 100GBASE-CR4 & 200GBASE-CR4, and InfiniBand QDR/FDR/EDR/HDR

Request Discount

The 200G QSFP56 to QSFP56 Direct Attach Cable is a high-performance, cost-effective passive copper interconnect for LAN, HPC, and SAN environments. Supporting 4-channel full-duplex transmission at up to 28GBaud PAM4 per lane, it delivers a maximum aggregate data rate of 200Gb/s and meets or exceeds 200 Gigabit Ethernet and InfiniBand EDR/HDR performance and temperature requirements. The QSFP56 form factor conforms to SFF-8636 and is backward compatible with QSFP28 MSA, making it suitable for 40GE/100GE/200GE switch, router, and HBA deployments. Each cable carries a customizable EEPROM signature accessible via the I²C two-wire serial interface for asset tracking and vendor identification.

Form FactorQSFP56
Modulation FormatPAM4
Max. Data Rate200Gbps
Max. Data Rate per Lane28 GBaud/s
MediaCopper
Cable DistanceUp to 3m
Power Supply3.3V
Cable TypePassive Twinax
Wire AWG30AWG(1m & 2m) | 26AWG(3m)
ProtocolsIEEE802.3cd, IEEE802.3bj
Temperature Range0°C to 70°C
Humidity(non-condensing)5 -95%
