10GBASE-LR SFP+ 1310nm 10km DOM Duplex LC Optical Transceiver Module
$16.00
- Hot pluggable SFP+ module and LC Duplex optical interface
- 1310nm DFB transmitter and PIN receiver
- Designed for 10km SMF connections
- All-metal housing for optimal EMI shielding
- RoHS-compliant and Class 1 laser safety compliant
- Complies with IEEE 802.3ae 10GBASE-LR/LW standards
- The firmware supports customer system encryption
- Operates from 0°C to 70°C (Commercial) and low power consumption
- Digital Diagnostic Monitoring (DDM) support for real-time monitoring
- Compatible with single-mode fiber infrastructure
- Long-reach capability for campus and metropolitan area networks
Note: Prices are exclusive of customs duties, import taxes, and VAT. Any additional charges imposed by your country are the buyer's responsibility.
The SFP+ LR optical transceiver supports 10 Gigabit Ethernet connectivity via single-mode fibers up to 10 kilometers. It operates at 1310nm and features DFB lasers and PIN photodetector technology. This hot-pluggable module offers high-quality long-reach connectivity for the most demanding network environments.
The all-metal enclosure provides the highest EMI protection and thermal management, and its standard LC duplex connector is able to provide seamless integration, without interruption of service. Digital Diagnostic Monitoring allows the monitoring of parameters in real-time to ensure proactive management of networks and troubleshooting. The support for encryption in firmware increases the security of the transmission of sensitive information.
Operating from 0°C to 70°C and consuming low power consumption of less than 4V, the module complies with RoHS as well as Class 1 laser safety standards while maintaining IEEE 802.3ae compliance to ensure broad compatibility of equipment. It is ideal for metropolitan areas, network campuses, backbone connections to campus, data center interconnects, as well as distributed facility connections in which extended reach capabilities are necessary.
Specifications
Form Factor | SFP+ | Connector | Duplex LC |
Media | SMF | Max. Cable Distance | 10km |
Data Rate | 10Gbps | Wavelengths Range | 1310nm |
Transmitter Type | DFB Laser | Receiver Type | PIN |
Extinction Ratio | >3.5dB | Receiver Overload | > 0.5dBm |
Supply Voltage | 3.3V | Power Consumption | <1W |
Op. Temperature | 0 to 70°C (32 to 158°F) | Humidity(non-condensing) | 0-85% |
St. Temperature | -40 to 85°C (-40 to 185°F) | Electrical Interface | Hot-pluggable |
Application | 10GBASE-LR Ethernet | Protocols | IEEE 802.3ae |
Connectivity solution
| Compatible Brands | Generic, Asterfusion, Arista, Nvidia, Juniper, Cisco, HUAWEI, H3C, Ruijie |
|---|
Warranty & Delivery Information
Warranty
Quality Certifications
Delivery Time
Our standard products are typically shipped within one week (business days).
For custom products, please contact customer service to inquire about the specific delivery time.
