100G QSFP28 Passive DAC

SKU:

DAC | QSFP28 to QSFP28 | 5m

  • Maximum aggregate data rate of 100Gb/s (4 × 25.78Gb/s)

  • Copper link length up to 5m

  • Power supply +3.3V

  • Low crosstalk design

  • Operating temperature range: 0°C to 70°C

  • Compliant with InfiniBand EDR and QSFP28 MSA

Request Discount

The 100G QSFP28 to QSFP28 Direct Attach Copper Cable is a high-performance, cost-effective passive copper interconnect built for LAN, HPC, and SAN environments. Supporting 4-channel full-duplex transmission at 25.78Gb/s per lane, it delivers a 100Gb/s aggregate data rate and meets or exceeds 100 Gigabit Ethernet and InfiniBand EDR performance and temperature requirements. The QSFP28 form factor conforms to SFF-8665 and SFF-8436, ensuring reliable connectivity across QSFP-based switches, routers, and HBAs. Each cable carries a customizable EEPROM signature accessible via the I²C two-wire serial interface for asset tracking and vendor identification. Available in 1m, 2m, 3m, and 5m lengths with 26AWG to 30AWG wire gauge options, the cable balances signal integrity with cable flexibility for dense rack deployments.

Form FactorQSFP28 (conforms to SFF-8665)
Connector TypeQSFP28 to QSFP28
Channel Count4-channel full-duplex
Media TypePassive Twinax copper
Max. Data Rate100Gb/s (4×25.78Gb/s aggregate)
Data Rate per Lane1–25.78 Gb/s
Power Supply Voltage3.14V min / 3.3V typ / 3.47V max
Management InterfaceI²C two-wire serial, customizable EEPROM
Operating Case Temperature0°C to +70°C
Storage Ambient Temperature−40°C to +85°C
